SOCAY Diodes Components R6 Package 30000W TVS 30KPA156CA 30KPA Series Axial Lead Transient Voltage Suppressors
SKU: 30KPA156CA
(0)
0 Sold
$2.66
$2.67
The Price Is For Reference Only. Please Consult Customer Service.
Reverse Stand-Off Voltage VRWM (V)：156.0
Breakdown Voltage VBR(V) @IT(Min)：174.3
Breakdown Voltage VBR(V) @IT(Max)：191.73
Test Current IT (mA)：5.0
Maximum Clamping Voltage VC@IPP (V) ：245.0
Maximum Peak Pulse Current IPP (A)：123.7
Maximum Reverse Leakage IR@VRWM (μA)：2.0
